Policy-Based Routing in Linux

When a Linux host has two network interfaces (e.g., eth0 on VLAN 10, eth1 on VLAN 30), the kernel has one main routing table with one default route. Without policy routing:

• Traffic from eth1 may exit via eth0's gateway (wrong VPN, wrong path)
• Return traffic may arrive on eth1 but reply via eth0, breaking the connection (asymmetric routing)
• Services bound to eth1's IP can't communicate reliably

Policy-based routing solves this by saying: traffic sourced from eth1's IP uses a separate routing table with eth1's gateway.

Concepts

Step 1 — Register the Table Name

Linux routing tables are identified by number (0–255 reserved, 1–252 usable). You give them names by adding an entry to /etc/iproute2/rt_tables:

echo "100 storage" >> /etc/iproute2/rt_tables

This maps the name storage to table ID 100. You can use any name and any unused ID.

⚠️ Critical: If the name isn't in rt_tables, every command referencing table storage will silently fail — post-uplines in /etc/network/interfaces won't error out, they just won't do anything. Always add the name first.

Verify:

cat /etc/iproute2/rt_tables | grep storage

Step 2 — Add Routes to the New Table

# Route for the local subnet via eth1
ip route add 192.168.1.0/24 dev eth1 src 192.168.1.50 table storage

# Default route for this table (traffic that isn't local goes via eth1's gateway)
ip route add default via 192.168.1.1 dev eth1 table storage

Verify:

ip route show table storage

Expected output:

default via 192.168.1.1 dev eth1
192.168.1.0/24 dev eth1 scope link src 192.168.1.50

If you get Error: ipv4: FIB table does not exist — the table is empty (no routes yet), not that the name is wrong.

Step 3 — Add the Routing Rule

The rule tells the kernel: "when traffic is sourced from 192.168.1.50, use the storage table."

ip rule add from 192.168.1.50 table storage priority 100

The priority 100 sets rule precedence — lower numbers are checked first. The default rules are at 0, 32766, and 32767, so 100 is evaluated early.

Verify:

ip rule show

Expected output:

0:      from all lookup local
100:    from 192.168.1.50 lookup storage
32766:  from all lookup main
32767:  from all lookup default

Step 4 — Test

# Verify eth1 can reach its gateway
ping -I eth1 192.168.1.1

# Verify internet reachability via eth1
ping -I eth1 8.8.8.8

# Check what IP the internet sees (should be eth1's VPN IP)
curl --interface eth1 https://ifconfig.me

Note: ICMP (ping) is often blocked by VPN providers. If ping to 8.8.8.8 fails but curl returns an IP, the interface is working fine.

Step 5 — Make It Persistent

The routes and rules above are lost on reboot. Persist them using post-up and pre-down hooks in /etc/network/interfaces:

auto eth1
iface eth1 inet static
    address 192.168.1.50/24
    gateway 192.168.1.1
    post-up ip route add 192.168.1.0/24 dev eth1 src 192.168.1.50 table storage
    post-up ip route add default via 192.168.1.1 dev eth1 table storage
    post-up ip rule add from 192.168.1.50 table storage priority 100
    pre-down ip rule del from 192.168.1.50 table storage priority 100

The post-up lines run after the interface comes up. The pre-down line cleans up the rule when the interface goes down.

Test persistence:

ifdown eth1 && ifup eth1
ip route show table storage    # should still be populated
ip rule show                   # rule should still be present

Troubleshooting

Quick Reference
